- High quality imaging with 9 MP resolution (1”GMOS)
- Excellent low-light performance, Color: 0.001 Lux @ (F1.4, AGC ON), 0.0005 Lux with IR
- Efficient H.265 compression technology
- 3D DNR technology delivers clean and sharp images
- Support license plate recognition (LPR)
- Vehicle feature recognition: vehicle type / color / manufacturer / license plate color recognition, no-plate vehicle capture
- Violation behaviors detection: driving on lane line, lane change, wrong-way driving detection, seatbelt and phone call detection
Application Scenarios: highway, tunnel, toll station, urban road, etc
Specifications
| Camera | |
| Image Sensor | 9 MP (1'' GMOS) |
| Max. Resolution | 4096 × 2160 |
| Min. Illumination | Color: 0.001 Lux @ (F1.4, AGC ON), 0.0005 Lux with IR |
| Shutter Time | 50 us-20000 us |
| Day & Night | IR cut filter |
| Lens | |
| Lens Type |
Fixed focal lens, 25 mm, Varifocal lens, manual adjustment, 11 to 40 mm, (AF) Model: Varifocal lens, motorized lens, 11 to 40 mm |
| Focal Length & FOV |
25 mm, horizontal FOV 32°, vertical FOV 16.8°, diagonal FOV 36.3°,, 11 to 40 mm, horizontal FOV 62° to 23.6°, vertical FOV 32.2° to 12.2°, diagonal FOV 70° to 26.8 |
| Focus | Manual, (AF) Model: Auto |
| Aperture | F1.6-C/F1.6-25/F1.6 |
| Illuminator | |
| Built-in Supplement Light Type | IR light |
| Light Bead | 2 |
| Built-in Supplement Light Range | Up to 30 m |
| IR Wavelength | 850 nm |
| External Supplement Light | Strobe and flash light |
| Video | |
| Main Stream |
50 Hz: 50 fps (4096 × 2160, 3840 × 2160, 3392 × 2008, 3072 × 1728, 2688 × 1520, 1920 × 1200, 1920 × 1080, 1280 × 720) 60 Hz: 30 fps (4096 × 2160, 3840 × 2160, 3392 × 2008, 3072 × 1728, 2688 × 1520, 1920 × 1200, 1920 × 1080, 1280 × 720) |
| Sub-Stream |
50 Hz: 50 fps (3392 × 2008, 2688 × 1520, 1920 × 1080, 1280 × 720, 704 × 576) 60 Hz: 30 fps (3392 × 2008, 2688 × 1520, 1920 × 1080, 1280 × 720, 704 × 576) |
| Third Stream |
50 Hz: 50 fps (1920 × 1080, 1280 × 720, 704 × 576) 60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 576) |
| Video Compression |
Main stream: H.265/H.264/MJPEG, Sub-stream: H.265/H.264/MJPEG, Third stream: H.265/H.264/MJPEG |
| Video Bit Rate | 32 Kbps to 16 Mbps |
| H.264 Type | Baseline profile/Main profile/High profile |
| H.265 Type | Main Profile |
| Network | |
| Protocols | TCP/IP,ICMP,HTTP,HTTPS,FTP,DNS,RTP,RTSP,RTCP,NTP,SNMP,802.1X,IPv4/IPv6,UDP,IS UP,ARP,IGMP |
| Simultaneous Live View | Up to 6 channels |
| API | ONVIF (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, ISUP |
| User/Host |
Up to 32 users 3 user levels: administrator, operator and user |
| Security |
Password protection, complicated password, HTTPS encryption, control timeout settings, 802.1X authentication (EAP-PEAP, EAP-LEAP, EAP-MD5), basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface |
| Network Storage | Micro SD/TF card (512 GB), local storage, CVR, NVR, ANR |
| Client | VIMS |
| Web Browser | Chrome V61+, IE9 to IE11, Firefox V41+, Edge |
| Image | |
| Image Settings |
Saturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or web browser. |
| Day/Night Switch | Auto/Scheduled/Triggered by alarm in |
| SNR | 60 dB |
| Image Enhancement | BLC, HLC, 3D DNR |
| Picture Overlay | LOGO picture can be overlaid on video with 128 × 128 24-bit bmp format. |
| Interface | |
| Ethernet Interface | 2 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port(s) |
| On-Board Storage | Built-in memory card slot, supporting microSD/SDHC/SDXC card card, up to 512 GB |
| Alarm | 2 input interfaces (T1, SYNC), 7 output interfaces |
| RS-485 | 3 RS-485 interfaces (half duplex, TBVISION) |
| RS-232 | 1 RS-232 interface |
| USB | 1 USB 2.0 interface |
| Event | |
| Basic Event |
HDD Error, network disconnected, IP address conflicted, vehicle detector exception, traffic light detector exception |
| Road Traffic and Vehicle Detection | |
| Coverage | Up to 3 lane(s) |
| Trigger Mode | External I/O trigger/Radar trigger/Video trigger |
| Smart Function | License plate recognition, vehicle type classification, vehicle color recognition, no-plate vehicle capture, moving direction detection |
| Accuracy (Under recommended installation and lighting conditions) | Capture rate > 99%, Vehicle moving direction recognition accuracy > 98.5%, LPR accuracy > 98%, Mistaken capture rate < 2% |
| No License Plate Detection | Supported |
| Motorcycle LPR | Supported |
| Vehicle Type | Car, Van, Bus, Truck, Light Truck, SUV(MPV), Pickup, Motorcycle, Tricycle |
| Vehicle Color |
Red, yellow, green, blue, pink, purple, cyan, brown, white, grey, black Recognizable at daytime only. |
| License Plate Color Recognition | Customized to support |
| Driving on Lane Line Detection | Supported (only strobe light mode) |
| Lane Change Detection | Supported (only strobe light mode) |
| Wrong-Way Driving Detection | Supported |
| Emergency Lane Occupation | Supported (truck forbidden lane, emergency lane, urban bus lane) |
| Seatbelt Detection | Supported (with flash supplement light) |
| Phone Call Detection | Supported (with flash supplement light) |
| Capture Speed Range | 10 to 320 km/h |
| General | |
| Operating System | Linux |
| Power | AC 100 V to 240 V, 1.5 A, max. 35 W, 3-core terminal block |
| Material | Aluminum alloy |
| Dimension | 501.0 mm × 175.6 mm × 144.6 mm (19.72" × 6.92" × 5.69") (L × W × H) |
| Package Dimension | 667 mm × 357 mm × 224 mm (26.26" × 14.06" × 8.82") (L × W × H) |
| Weight | Approx. 5.13 kg (11.31 lb.) |
| With Package Weight | Approx. 7.4 kg (16.31 lb.) |
| Operating Condition | -30 °C to 70 °C (-22 °F to 158°F). Humidity: 5% to 95% (non-condensing) |
| Storage Condition | -30 °C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing) |
| General Function | Password protection, three streams, heartbeat, one-key reset, pixel counter |
| Heater | Supported |
| Language |
8 languages: English, Russian, Croatian, Korean, Russian, Traditional Chinese, Ukrainian, Spanish |
| Approval | |
| EMC | CE-EMC: EN 55032: 2015/A11:2020+A1:2020, EN IEC61000-3-2: 2019/A1:2021, EN 61000-3-3: 2013+A1:2019/A2:2021, EN 50130-4: 2011 +A1: 2014 |
| Safety | CE-LVD: EN 62368-1: 2014/A11: 2017, CB: IEC 62368-1: 2014+A11, CB: IEC 62368-1: 2018+A11 |
| Environment | CE-RoHS: 2011/65/EU,WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006 |
| Protection | IK10: IEC 62262:2002, IP66: IEC 60529-2013 |
