• 1/2.8" Progressive Scan CMOS
• 2592 × 1944 @30fps at 60 Hz
• 2.7 to 13.5 mm varifocal lens
• Color: Color: 0.003 Lux @ (F1.4, AGC ON), B/W: 0 Lux with IR
• H.265+, H.265, H.264+, H.264
• Three streams
• 120dB WDR
• BLC/3D DNR/ROI/HLC
• P67, IK10
• Built-in micro SD/SDHC/SDXC card slot, up to 256 GB
• 3-Axis adjustment
Specifications
| CAMERA | |
| Image Sensor | 1/2.8" progressive scan CMOS |
| Illumination Color | Color: 0.003 Lux @ (F1.4, AGC ON), B/W: 0 Lux with IR |
| Shutter Speed | 1/3 s to 1/100,000 s |
| Day & Night | IR Cut Filter |
| Angle Adjustment | Pan: 0°to 360°, tilt: 0°to 90°, rotate: 0°to 360° |
| S/N Ratio | More than 50dB |
| WDR | 120dB |
| CAMERA FEATURES | |
| Max. IR LEDs Length | Up to 60 m |
| Day/Night | Auto(ICR) / Color / B/W |
| Backlight Compensation | BLC / HLC /WDR(120dB)/ 3D DNR |
| White Balance | Auto/Sunny/Night/Outdoor/Customized |
| Gain Control | Auto/Manual |
| Noise Reduction | 3D |
| Privacy Masking | Up to 4 areas |
| LENS | |
| Iris Type | Auto-iris |
| Lens Type | Varifocal lens 2.7 – 13.5 mm |
| Aperture | 2.7 to 13.5 mm: F1.4 |
| IMAGE | |
| Main stream | 50 Hz: 25 fps (2592 × 1944, 2688 × 1520, 1920 × 1080, 1280 × 720) 60 Hz: 24 fps (2592 × 1944) 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720) |
| Audio Compression | G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/ACC |
| Video Compression | Main Stream: H.265+/H.265/H.264+/H.264 Sub-Stream: H.265/H.264/MJPEG Third Stream: H.265/H.264/MJPE |
| Image Setting | 2592 × 1944 Max |
| Video Bit Rate | 32 Kbps to 16 Mbps |
| INTERFACE | |
| Alarm | 1 input, 1 output (max. 24 VDC/24 VAC, 1 A) |
| Audio | 1 input (line in); 1 output (line out) |
| Ethernet Interface | 1 RJ45 10 M/100 M |
| Edge Storage | Built-in micro SD/SDHC/SDXC slot, up to 256 GB |
| Reset Key | Yes |
| VCA FEATURES | |
| Smart Event | Line crossing detection, 1 line configurable Intrusion detection, up to 1 region configurable Unattended baggage detection, 1 region configurable Object removal detection, 1 region configurable Face detection: detects faces Scene change detection Audio exception detection |
| Event Detection | Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error) |
| NETWORK | |
| Network | IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, DHCP, PPPoE, UDP, IGMP, ICMP, Bonjour |
| Protocols Protocols | Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS 1.2, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, TLS1.2, AES Video Encryption 128 bits. |
| Web Language | English, Russian, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian … |
| GENERAL | |
| Power Supply | 12 VDC ± 25%, 1.08 A, max. 13 W, two-core terminal block PoE: 802.3at, Class 4, 42.5 V to 57 V, 0.36 A to 0.27 A, max. 15 W |
