Specifications
| Camera | |
| Image Sensor |
[Bullet channel] 1/1.8" Progressive Scan CMOS, [PTZ channel] 1/1.8" Progressive Scan CMOS |
| Max. Resolution | [Bullet channel] 2560 × 1440, [PTZ channel] 2560 × 1440 |
| Min. illumination |
[Bullet channel]: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light; [PTZ channel]: Color: 0.005 Lux @ (F1.5, AGC ON), B/W: 0.001 Lux @ (F1.5, AGC ON), 0 Lux with IR |
| Shutter Time | 1 s to 1/30,000 s |
| Slow Shutter | Yes |
| Day & Night |
ICR |
| Lens | |
| Focal Length | [Bullet channel] 2.8 mm, [PTZ channel] 5.9 to 188.8 mm |
| Zoom | [PTZ channel] 32 × optical, 16 × digital |
| Iris | Auto/Manual |
| Focus | Auto/Manual/Semiauto |
| Aperture | [Bullet channel]: F1.0; [PTZ channel]: F1.5 |
| FOV |
[Bullet channel] horizontal field of view: 108°, vertical field of view: 56°, diagonal field of view: 134°, [PTZ channel] horizontal field of view: 60.2° to 2.3°, vertical field of view: 35.2° to 1.3°, diagonal field of view: 67.4° to 2.6° |
| Illuminator | |
| Supplement Light Type | [Bullet channel] IR, [PTZ channel] IR |
| Supplement Light Range | [Bullet channel] IR: up to 30 m, [PTZ channel] IR: up to 200 m |
| Smart Supplement Light | Yes |
| PTZ |
|
| Movement Range | Pan: 360°, Tilt: -15° to 90° (auto flip) |
| Pan Speed | Configurable from 0.1° to 80°/s; preset speed: 80°/s |
| Tilt Speed | Configurable from 0.1° to 80°/s, preset speed 80°/s |
| Proportional Pan | yes |
| Presets | 300 |
| Preset Freezing | yes |
| Patrol Scan | 8 patrols, up to 32 presets for each patrol |
| Pattern Scan | 4 pattern scans, record time over 10 minutes for each scan |
| Park Action |
Preset, patrol scan |
| 3D Positioning | yes |
| PTZ Status Display | yes |
| Scheduled Task |
Preset, patrol scan, dome reboot, aux output, dome adjust |
| Power-off Memory | yes |
| Video and Audio | |
| Streaming Capability | Multiple streaming (3 Streams) |
| Main Stream |
[Bullet channel] 50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720), 60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720), [PTZ channel] 50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720), 60 Hz: 24 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720) |
| Sub-Stream |
[Bullet channel] 50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288), 60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240), [PTZ channel] 50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288), 60 Hz: 24 fps (704 × 480, 640 × 480, 352 × 240) |
| Third Stream |
[Bullet channel] 50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288), 60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240), [PTZ channel] 50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288), 60 Hz: 24 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240) |
| Video Compression |
Main stream: H.265+/H.265/H.264+/H.264, Sub-stream: H.265/H.264/MJPEG, Third stream: H.265/H.264/MJPEG |
| Video Bit Rate | 32 Kbps to 16 Mbps |
| Scalable Video Coding (SVC) |
H.264 and H.265 encoding |
| Region of Interest (ROI) | 8 fixed regions for each stream |
| Audio Compression | G.711, G.722.1, G.726, MP2L2, MP3, PCM, AAC-LC |
| Audio Sampling Rate | AAC-LC: 16 kHz, 32 kHz, 48 kHz,MP2L2: 16 kHz, 32 kHz, 48 kHz,PCM: 8 kHz, 16 kHz, 32 kHz, 48 kHz,MP3: 8 kHz, 16 kHz, 32 kHz, 48 kHz |
| Environment Noise Filtering | Yes |
| Network | |
| Security | Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), IP address filter |
| API | ONVIF (profile S/G/T), SDK, Open-ended API |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, 802.1X, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, UDP, IPv4/IPv6, IGMP, DHCP, Bonjour, WebSocket |
| User/Host | Up to 32 users, 3 user levels: administrator, operator, and user |
| Network Storage | NAS (NFS, SMB/CIFS), ANR |
| Web Browser | IE 10+, Chrome 57+, Firefox 52+, Safari 12+ |
| Mobile Communication | |
| Mobile Communication Type | 4G |
| Frequency | |
| Standard | |
| Image | |
| Image Parameters Switch | Yes |
| Image Settings | Saturation, brightness, contrast, sharpness |
| Day/Night Switch | Day, night, auto, scheduled-switch |
| Wide Dynamic Range (WDR) | 120 dB |
| SNR | > 52dB |
| Image Enhancement | BLC, HCL, Defog, 3D DNR, EIS (Built-in gyroscope to improve EIS performance) |
| Regional Focus | yes |
| Regional Exposure | yes |
| Interface | |
| Ethernet Interface | RJ45, self-adaptive 10M/100M Ethernet port |
| On-Board Storage | Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB |
| Audio |
1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%, 1 output (line out), line level, output impedance: 600 Ω
|
| Alarm | 2 input(s), 1 output(s) |
| Reset Key | Yes |
| Power Output | 12 VDC, max. 1000 mA |
| Event |
|
| Basic Event |
[PTZ channel] motion detection, video tampering alarm, [PTZ channel & bullet channel] alarm input and output, exception |
| Smart Event | [PTZ channel] line crossing detection, intrusion detection, region entrance detection, region exiting detection |
| Linkage |
[Bullet channel] Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, and trigger recording, [PTZ channel] Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, and PTZ actions (such as preset, patrol scan, pattern scan) |
| Smart Tracking | [PTZ channel] yes |
| Smart Linkage | Manual tracking, auto tracking, tracking takeover, track in turn |
| Deep Learning Function | |
| Face Capture | [Bullet channel] no,[PTZ channel] yes |
| General | |
| Power | 12 VDC ± 25%, max. 28 W,Typical power scenarios: 8.7 W (4G working); Standby scenarios: 7.7W (4G working); Sleep mode: 100 mW |
| Dimension | Ø 220 mm × 382.1 mm (Ø 8.66" × 15.04") |
| Weight | Approx. 6 kg (13.23 lb.) |
| Material | Metal |
| Operating Condition | -30 °C to 65 °C (-22 °F to 149 °F). Humidity 90% or less (non-condensing) |
| Protection | IP67, IK10 |
| General Function | mirror, password protection, watermark, IP address filter |
| Demist | Demist by heating the glass |
| Battery | |
| Battery Type | Lithium |
| Battery Voltage | 9 to 12.6 V |
| Capacity | 360 WH (90 WH for each battery) |
| Max. Charging Voltage | 12.6 V |
| Operating Temperature | Charging: -20 °C to 45 °C (-4 °F to 113 °F) Discharging: -20 °C to 60 °C (-4 °F to 140 °F) |
| Cycle Lifetime | Performance mode: 1.5 days. Proactive mode: 2 days. Standby mode: 80 days *in cloudy/rainy days (25 °C) |
| Battery Life | More than 500 cycles |
| Battery Weight | Approx. 2.74 kg (6.0 lb.) (0.685 kg (1.5 lb.) for each battery) |
